OpenID Connect (client side)

Oneki.js supports the Open ID Connect (OIDC) authorization code flow where the authorization code is exchanged for an access token via a server. This is the most common and secure way to retrieve the access token

In settings.js, when the "idp type" is "oidc_server", Oneki.js implements the following scenario:

To authenticate against an OpenID Connect Identity Provider (OIDC IDP), you have to create four pages/routes:

• login: this page is displayed following a click on a link or a redirect following a 401 HTTP Error
• login callback: this route is called by the OIDC IDP (e.g: Google) after a successfull authentication
• logout: this page is displayed following a click on a logout link or if there is no activity for x minutes (configurable via settings)
• logout callback: this route is called by the OIDC IDP after a successfull logout

The code is the same for a NextJS App or a Create React App

Login

import React from "react";
import { useLoginService } from "onekijs";

export default React.memo(() => {
  const idpName = 'google';
  const options = {};
  const [error] = useLoginService(idpName, options);
  if (error) {
    return <div>{error.payload.message} <span onClick={() => error.remove()}>X</span></div>
  }
  return null;
}

Parameters

Inputs

// [Optional] the name of the IDP used for the login -- defaults to "default"
idpName: string

// [Optional] options object -- defaults to {}
options: {

  // a callback function triggered when an error is thrown -- defaults to send error on topic "login-error"
  onError: func
}

Outputs

error: {
  payload: {
    // description of the error
    message: string,

    // code of the error
    code: string,
  }

  // remove the error
  remove: func
}

Login Callback

import React from "react";
import { useLoginCallbackService } from "onekijs";

export default React.memo(() => {
  const idpName = 'google';
  const options = {};
  const [error] = useLoginCallbackService(idpName,options);
  if (error) {
    return <div>{error.payload.message} <span onClick={() => error.remove()}>X</span></div>
  }
  return null;
}

Parameters

Inputs

// [Optional] the name of the IDP used for the login -- defaults to "default"
idpName: string

// [Optional] options object -- defaults to {}
options: {
  // a callback function triggered when an the login is successfull -- The default redirects the user from the calling page
  onSuccess: func
  // a callback function triggered when an error is thrown -- defaults to send error on topic "login-error"
  onError: func
}

Outputs

error: {
  payload: {
    // description of the error
    message: string,

    // code of the error
    code: string,
  }

  // remove the error
  remove: func
}

Logout

import React from "react";
import { useLogoutService } from "onekijs";

export default React.memo(() => {
  const options = {};
  const [error] = useLogoutService(options);
  if (error) {
    return <div>{error.payload.message} <span onClick={() => error.remove()}>X</span></div>
  }
  return null;
}

Parameters

Inputs

// [Optional] options object -- defaults to {}
options: {
  // a callback function triggered when an error is thrown -- defaults to send error on topic "logout-error"
  onError: func
}

Outputs

error: {
  payload: {
    // description of the error
    message: string,

    // code of the error
    code: string,
  }

  // remove the error
  remove: func
}

Logout Callback

import React from "react";
import { useLoginCallbackService } from "onekijs";

export default React.memo(() => {
  const options = {};
  const [error] = useLogoutCallbackService(options);
  if (error) {
    return <div>{error.payload.message} <span onClick={() => error.remove()}>X</span></div>
  }
  return null;
}

Parameters

Inputs

// [Optional] options object -- defaults to {}
options: {
  // a callback function triggered when an the logout is successfull -- The default redirects the user to the home page
  onSuccess: func
  // a callback function triggered when an error is thrown -- defaults to send error on topic "logout-error"
  onError: func
}

Outputs

error: {
  payload: {
    // description of the error
    message: string,

    // code of the error
    code: string,
  }

  // remove the error
  remove: func
}

Configuration

useLoginService, useLoginCallbackService, useLogoutService, useLogoutCallbackService are fully configured in settings.js
The configuration must be defined under the key "idp/:idpName". For example, if idpName=google, the config must look like this:

const settings = {
  idp: {
    google: {
      type: "oidc_server",
      ...
    }
  }
}

Mandatory attributes

Key	Type	Description
authorizeEndpoint	string | function(context)	Can be a string (relative or absolute URL) or a function returning the URL if it's a relative URL, it's prefixed by the server.baseUrl from settings.js
clientId	string	the client_id created on the IDP (identity provider)
logoutEndpoint	string | function(context)	Can be A relative or absolute URL A function returning the URL if it's a relative URL, it's prefixed by the server.baseUrl from settings.js
tokenEndpoint	string | function(grant_type, context)	Can be a relative or absolute URL A function that does an AJAX POST request to the token endpoint and returns a object of type "Token" if it's a relative URL, it's prefixed by the server.baseUrl from settings.js
type	string	must be "oidc_server"
userinfoEndpoint	string | function (context)	Can be: A relative or absolute URL A function that returns an object that represents the userInfo. For example a object like this: {email: 'foo@example.com', roles: ['ADMIN']}} if it's a relative URL, it's prefixed by the server.baseUrl from settings.js

Optional attributes

Key	Type	Description	Default
callback	function(response, context): [token,userInfo]	Callback called at the end of the authentication for extracting the token and the userInfo from the response. Inputs response: the response from the authentication server context: an object containing the configuration of the IDP used, the redux store, the router, the settings and i18n infos Outputs token: the oauth2 token userInfo: the securityContext of the user	null
codeChallengeMethod	string	Method that was used to derive an authorization code challenge	S256
jwksEndpoint	string | function(token, context)	jwksEndpoint is mandatory if validate = true. Can be A relative or absolute URL A function that returns a public key if it's a relative URL, it's prefixed by the server.baseUrl from settings.js	null
loginCallbackRoute	string	a relative or absolute URL called by the OIDC server after a successfull login.	[loginRoute]/callback
logoutCallbackRoute	string	a relative or absolute URL called by the OIDC server after a successfull logout. Should be used to remove the cookie on the server side	[logoutRoute]/callback
pkce	boolean	flag to indicate if the PKCE extension is applied. Recommended	true
nonce	boolean	flag to indicate if the nonce in the id_token is validated on the client side. Should be done on the server side	false
postLoginRedirectKey	string	When calling the authorize endpoint, postLoginRedirectKey represents the name of the parameter to indicate the redirect URI	redirect_uri
postLogoutRedirectKey	string	When calling the logout endpoint, postLoginRedirectKey represents the name of the parameter to indicate the redirect URI	post_logout_redirect_uri
responseType	string	only code is supported right now	code
scope	string	the value of the parameter "scope" sent to the authorize endpoint. Should generally be redefined	openid
state	boolean	flag to indicate if the javascript client send a state to the IDP. Recommended for mitigating attacks	true
validate	boolean	flag to indicate if the id_token and the access_token are validated. Should generally be done on the server side	false

Configuration example

const settings = {
  idp: {
    google: {
      type: 'oidc_server',
      clientId: '1eb5cq6p7d8dm8g4q9jk6qdve5', // id given by Google
      authorizeEndpoint: 'https://accounts.google.com/o/oauth2/v2/auth', // URL given by Google. Will be called by the client
      tokenEndpoint: '/api/oauth2/token',   // URL of a service exposed by your server that exchanges the authorization code for an access token by calling the Google /token endpoint
      userinfoEndpoint: '/api/oauth2/userinfo', // URL of a service exposed by your server that returns the details about the logged-in user
      logoutEndpoint: '/api/oauth2/logout', // URL exposed by your server which call the IDP logout URL and then removes the cookie
      scope: 'openid email profile', // ask to Google the profile and the email of the user
    }
  }
}
